CJLP40-BA
Liquid pump
CJLP40-BA
cjlp40-ba
Applications
High-end medical equipment, Coffee maker, Water dispenser, Water circulating equipment, Kitchen and bathroom, Sterilization etc.
Specifications
Sub-category
Eccentric diaphragm liquid pump
Electrical
Voltage
DC 24 V
Current under no load
< 800 mA
Max current
< 1500 mA
Rated power
<36W
Rated voltage of motor (recommended range)
DC3-36V
Performance
Free flow
>1500 mL/min
Max head / Max pressure
>10 bar
Medium
Water
Noise
< 70 dB
Environmental
Working environment
1°C~45°C, 30~80%RH
Durability
Life test
500 H (room temperature, back pressure 10 bar, run 3min / stop 1min per cycle)
Physical
Pump head dimensions
≤80*80mm
Other
Different voltage available
Different voltage available
